IP66 Low Voltage Lighting


Great New LED Cylinder Light

Brighter than normal lights

Energy saving


 24v,48vIP66 Led Waterproof  fitting

Our stunning IP66 waterproof LED cylinder light fitting is perfect for today’s environments, with its slim design and amazing 3000 lumen light output. It is constructed in the UK using the latest electronics and LED technology on the market today.

It has outstanding energy efficiency on running costs compared to other similar LED fittings on the market within the UK.

The IP66 waterproof LED cylinder has the capability to be used in damp and dusty or wet conditions. It can withstanding  shocks  vibrations of everyday life makes it outperform any T8 fluorescent tube fittings and even T5 fittings. The IP66 waterproof cylinder is a perfect replacement fitting as it is easy to install in most places with just two plastic terry clips.

This waterproof fitting is only 1180mm long and has an impressive 5200 lumens, almost 5 times brighter than a normal 18w T8 fluorescent tube and 4 times brighter than a 24w T5 fluorescent tube.

The unit LEDs are mounted smartly on a robust C-shape aluminium heat sink chassis with all the wires and electronics very neatly contained inside the chassis. They are held inside an IP66 waterproof clear plastic tube with 2 water-tight white or black endcaps with a 1m PVC flex coming out of one end cap.

The led colour temperature is normal at 6000k and can be changed; please call (01704 841073) for more information.

It comes with 2 x 52mm plastic terry clips (white or black).

It can run on 24V, 48V DC, or 24V AC and it complies with IEC and FCC electrical and safety standards.

It comes with a 1 meter, 3 core lead, or can be longer if required.

The led Cyl48 light can be directional.

Ideally used for machinery, Convergys, washing down.

Linear Led Cylinder lights

Code Length Current Volts Lum
Cyl12DC 320mm 0.07mA 12v DC 2500
Cyl24DC 320mm 0.035mA 24v DC 2500
Cyl12AC 320mm 0.07mA 12v AC 2500
Cyl24AC 320mm 0.035mA 24v AC 2500
Cyl48DC 620mm 0.7mA 24v DC 3500
Cyl50DC 620mm 0.7mA 48v DC 6700
Cyl48AC 620mm 0.7mA 24v AC 3500
Cyl50AC 620mm 0.7mA 48v AC 6700
Cyl96DC 1140mm 1.4mA 24v DC 7000
Cyl248DC 1140mm 1.4mA 48v DC 13,400
Cyl96AC 1140mm 1.4mA 24v AC 7000
Cyl248AC 1140mm 1.4mA 48v AC 13,400

Additional information

Low Voltage Linear Lights

Cyl12AC, Cyl12DC, Cyl248DC, Cyl24AC, Cyl24DC, Cyl48AC, Cyl48DC, Cyl50AC, Cyl50DC, Cyl96DC

Black or White Caps

Black Caps, white Caps
